Grade C45 Sample MTC Certificate
Access a comprehensive, professionally formatted Material Test Certificate according to EN 10204-2004: 3.1 for Grade C45 carbon steel (EN 10083-2). Verify documentation featuring heat treatment records and chemical verification for high-reliability components.
What's Inside This Grade C45 MTC Certificate
This sample mill test certificate mirrors the rigorous documentation package shipped with every Grade C45 order from Ananka Fasteners.
- Full Traceability: Certified with exact Lot No.: FGLXXX and TC No.: S05/26-XXX linked to the production melt.
- Chemical Breakdown: Detailed results for Carbon (0.467%), Manganese (0.722%), and Phosphorus (0.019%) ensuring structural compliance.
- Heat Treatment Data: Logs specific Hardening (850°C) and Tempering (600°C) procedures with recorded oil quenching.
- Hardness Verification: Recorded results of 29.2, 30.5, 29.2 HRC meeting the maximum specified limit of 32 HRC.
- Dimensional Conformance: Confirmation of inspection as per PO Specification (DIN 125).
- Surface Finish: Verification of blackening process application.
Live Preview: Grade C45 MTC Data
TC Number
S05/26-XXX
TC Date
02/04/202X
Heat Number
HT-C45XXX
Lot Number
FGLXXX
Hardening Temp
850°C (Oil Quenched)
Dimensions / Item
WASHER M16 (DIN 125)
Chemical Composition % (Actual Results)
| Carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) | Silicon (Si) |
|---|---|---|---|---|
| 0.467 | 0.722 | 0.019 | 0.027 | 0.174 |
| 0.42 - 0.50 | 0.50 - 0.80 | Max: 0.045 | Max: 0.045 | Max: 0.40 |
Hardness Property Verification
| Property | Specified Limit | Actual Result (HRC) |
|---|---|---|
| Surface Hardness | Max: 32 | 29.2, 30.5, 29.2 |
Standard References: EN 10083-2 Compliance
Our Grade C45 certificates confirm compliance with EN 10083-2 standards for non-alloy quality steels.
| Standard / Requirement | Confirmation on Certificate |
|---|---|
| Dimensional Spec | As per PO Specification (DIN 125). |
| Visual Inspection | 100% visual inspection carried out & found free from defects. |
| Weld Repairs | No weld repair performed. |
| Radioactive Contamination | Material is free from radioactive contamination. |
Ananka Fasteners' Certification Details
Documentation
- EN 10204 3.1 Standard
- ISO 9001:2015 Compliant
Processing
- Hardened at 850°C
- Tempering Temp: 600°C
- Oil Quench Verified
Finishing
- Blackening Finish Applied
- Dimensional Compliance Verified
Technical FAQs — Grade C45 MTC Certificate
What heat treatment methodology is tracked?
The MTC logs a hardening cycle at 850°C followed by an Oil Quench and a tempering cycle at 600°C.
What mechanical tests are logged?
The report focuses on Surface Hardness testing (HRC) to ensure the washers meet EN 10083-2 performance requirements.
Are visual and dimensional checks confirmed?
Yes, the document validates 100% visual inspection and conformance to DIN 125 dimensions.
