High Tensile Fasteners Manufacturer, High Tensile Bolts Stockist, High Tensile Nuts Supplier, High Tensile Screws Exporter – Ananka Group
Ananka Group is a leading High Tensile Fasteners Manufacturer in India, producing a wide range of high tensile fasteners in various sizes, grades, and scales. High Tensile Bolts / Nuts / Screws have higher tensile strength when compared to a regular bolt, nuts, or screw, they are much more popular due to their tensile strength and are used in various applications. most of the high tensile bolts, screws, or fasteners that are available in the market are blackish-colored alloys.
High Tensile Bolts, Nuts Fasteners
There are many grades available, including 10.9, 8.8, DIN 933, and 12.9 grades. Many other standards exist, including IS1364, IS1363, DIN EN ISO 4014, and others. These standards specify fastener sizes ranging from 20mm to 100mm. The various varieties, such as the High Nut Bolt, are used for various purposes. Threads bind the nut bolts together.
The High Tensile Bolt is a bolt with high tensile strength. The composition of a material can vary depending on its grade. Because of their high tensile strength, the majority of these are chromium nickel and nickel-copper alloys. M8 High Tensile Bolts have an 8mm diameter and come in a variety of lengths and material grades. Please contact us for more details on the pricing and availability of these high-tensile fasteners.
Type of High Tensile Fasteners
High Tensile Grades 8.8 Bolts
High Tensile Grades 10.9 Bolts
High Tensile Grades 12.9 Bolts
High Tensile Grades 14.9 Bolts
High Tensile Bolts / Nuts Specifications and Grades
| High Tensile Fasteners Material Specification | High Tensile Bolts |
| Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM, and all International Standards |
| High Tensile Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length | 3 mm to 200 mm |
| High Tensile Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF, or as required |
| High Tensile Fasteners Standard: | ANSI – American National Standards Institute
DIN: DIN 931, DIN 933, DIN 934, DIN 970 |
| Source of Raw Materials | Tata Steel, JSPL, RINL, Usha Martin, Dhamma Steel, Mukund Steel, etc. |
| Scope of Manufacture |
|
| High Tensile Fasteners in Form Of: | Hex, Square, Round, Threading as per Gauge Etc. |
| Head Drive: | Phillips, Slotted, Phillips/Slot, Six-Lobe, etc |
| High Tensile Bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
| High Tensile Fasteners Finishing: | Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel-plated, plated zinc-nickel, High Tensile: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, High Tensile, Mechanically Applied coating, and some special one like DACROMET |
| Production Process | M2-M24: Cold Forging, hot forging M24-M100, machining, and CNC for Customized connecting element |
| High Tensile Bolting Materials Surface Coating: |
All surface finishes offered including Geomet & PTFE, Galvanised, Zinc, Electroless Nickel, Sherardized, Dacromet |
| Popular Types of High Tensile Bolts | Hex Bolts, Flange Bolts, Hex Head Bolts, Lag Bolts, Square Bolts, Eye Bolts, U Bolts, T Bolts, Countersunk Bolts, etc. |
| Popular Types of High Tensile Nut | Eye, Dome, Hex Head Nut, Panel, Lock, Coupling, Square, Acorn, T, Wing, etc. |
| Popular Types of High Tensile Screw | Socket Set Fasteners, Anchor Fasteners, Blind Fasteners, Threaded Fasteners, Socket Head Fasteners, Machine Fasteners, Concrete Fasteners, Shoulder Fasteners, Panel Fasteners, Hex Head Cap Fasteners, etc. |
| Popular Types of High Tensile Washer | Machine Washers, Star Washers, Flat Washer, Lock Washer, Split Washer, Sealing Washer, etc. |
| High Tensile Fasteners Packing: | IN BULK: canton, pallet, Small Boxs / carton/pallet, or customer request |
Types Of High Tensile Bolts
HEX BOLTS, STUD BOLTS, ANCHOR BOLTS, EYE BOLTS, FLANGE BOLTS, SOCKET HED CAP SCREW, CSK, GRUB SCREW, HEXAGONAL HEAD BOLTS, ALLEN BOLTS, HUB BOLTS, T BOLTS, BENZO BOLTS, TRACK SHOE BOLTS.
Grades of High Tensile Bolts
High Tensile Grades 8.8 Bolts, High Tensile Grades 10.9 Bolts, High Tensile Grades 12.9 Bolts
Types of High Tensile Bolts
- High Tensile Allen Bolts
- High Tensile Anchor Bolts
- High Tensile Aluminium Bolts
- High Tensile Bsf Bolts
- High Tensile Brass Bolts
- High Tensile Eye Bolts
- High Tensile Galvanized Bolts
- High Tensile Hex Bolts
- High Tensile Hexagon Bolts
- High Tensile U Bolts
- High Tensile Unc Bolts
- High Tensile Unf Bolts
- High Tensile Bolts 12.9 Grade
- High Tensile Bolts 10.9
- High Tensile Bolts 12.9
- High Tensile Bolts 12.8
- High Tensile Steel Bolts 12.9
- 4mm High Tensile Bolts
- 5/16 High Tensile Bolts
- High Tensile Bolts 8.8
- Grade 8 High Tensile Bolts
M8 High Tensile Fasteners Weight Chart in mm
| Length in Milimeter | ||||||||||
| M 5 | M 6 | M 8 | M 10 | M 12 | M 14 | M 16 | M 18 | M 20 | M 22 | |
| 16 | 0.448 | 0.743 | 1.590 | 3.211 | ||||||
| 20 | 0.598 | 0.812 | 1.711 | 3.411 | 4.892 | |||||
| 25 | 0.660 | 0.897 | 1.871 | 3.660 | 5.252 | 8.170 | ||||
| 30 | 0.737 | 1.010 | 2.070 | 3.912 | 5.574 | 9.690 | 10.707 | 18.657 | ||
| 35 | 0.804 | 1.120 | 2.271 | 4.223 | 5.974 | 10.000 | 11.416 | 16.026 | 19.608 | |
| 40 | 0.881 | 1.230 | 2.470 | 4.533 | 6.410 | 10.288 | 12.107 | 16.667 | 20.747 | |
| 45 | 0.958 | 1.340 | 2.671 | 4.840 | 6.859 | 10.504 | 12.821 | 17.241 | 21.739 | |
| 50 | 1.030 | 1.450 | 2.870 | 5.155 | 7.299 | 11.261 | 13.624 | 17.857 | 22.727 | 28.409 |
| 55 | 1.560 | 3.071 | 5.464 | 7.740 | 11.628 | 14.409 | 18.868 | 23.810 | 30.120 | |
| 60 | 1.670 | 3.270 | 5.774 | 8.183 | 12.255 | 15.244 | 20.000 | 25.126 | 32.051 | |
| 65 | 1.781 | 3.472 | 6.083 | 8.621 | 12.626 | 16.026 | 21.008 | 26.455 | 34.014 | |
| 70 | 1.890 | 3.671 | 6.394 | 9.058 | 12.987 | 16.835 | 22.124 | 27.778 | 35.461 | |
| 75 | 2.000 | 3.873 | 6.702 | 9.506 | 13.228 | 17.606 | 23.256 | 29.070 | 39.063 | |
| 80 | 2.111 | 4.072 | 7.013 | 10.000 | 13.889 | 18.248 | 24.510 | 30.303 | 40.000 | |
| 90 | 4.472 | 7.634 | 10.917 | 14.925 | 19.841 | 26.042 | 33.113 | 41.667 | ||
| 100 | 4.873 | 8.251 | 11.820 | 16.340 | 21.459 | 27.778 | 35.714 | 46.296 | ||
| 110 | 8.881 | 12.723 | 17.730 | 23.041 | 31.250 | 38.168 | 47.170 | |||
| 120 | 9.506 | 13.624 | 18.797 | 24.631 | 32.895 | 40.984 | 50.000 | |||
| 130 | 10.101 | 14.535 | 20.000 | 26.316 | 34.722 | 43.478 | 52.632 | |||
| 140 | 10.707 | 15.432 | 20.833 | 27.933 | 35.461 | 46.296 | 55.556 | |||
| 150 | 11.312 | 16.340 | 22.222 | 29.412 | 37.594 | 48.544 | 58.824 | |||
| 160 | 11.905 | 17.241 | 24.272 | 31.056 | 40.984 | 50.505 | 61.728 | |||
| 170 | 12.500 | 18.116 | 32.680 | 53.191 | 64.935 | |||||
| 180 | 13.123 | 19.011 | 26.882 | 34.247 | 55.556 | 67.568 | ||||
| 190 | 13.736 | 19.920 | 35.971 | 58.140 | 70.423 | |||||
| 200 | 14.327 | 20.833 | 29.586 | 37.594 | 49.020 | 60.976 | 73.529 | |||
| 220 | 15.528 | 22.624 | 40.650 | 65.789 | 79.365 | |||||
| 240 | 16.722 | 24.510 | 43.860 | 71.429 | 84.746 | |||||
| 250 | 17.301 | 25.381 | 45.455 | 74.627 | 87.719 | |||||
| 260 | 17.921 | 26.316 | 47.170 | 76.923 | 90.909 | |||||
| 280 | 19.157 | 28.090 | 50.505 | 81.967 | 98.039 | |||||
| 300 | 20.325 | 29.940 | 53.763 | 87.719 | 104.167 | |||||
| 320 | 31.646 | 56.818 | 92.593 | |||||||
| 340 | 33.557 | 60.241 | 98.039 | |||||||
| 360 | 35.211 | 63.291 | 104.167 | |||||||
| 380 | 37.037 | 66.667 | 108.696 | |||||||
| 400 | 39.063 | 69.444 | 113.636 |
High Tensile Fasteners Price List
| High Tensile Fasteners Price List | Price Per Pcs. |
|---|---|
| High Tensile Machine bolts price | USD $5.12 |
| M10 HTHex head bolts price | USD $5.0 |
| ASTM F568 HT Socket Head Cap Screw price | USD $3.60 |
| HT Screws price | USD $4.70 |
| M8 High Tensile Dowel Pins price | USD $2.20 |
Get In Touch
High Tensile Fasteners Packaging and Delivery:-
- High Tensile Fasteners Payment Modes: LC (Letter of Credit), TT (Telegraphic Transfer or Wire Transfer), Cheque and others.
- High Tensile Fasteners Packaging: High Tensile Fasteners are packaged with caution and safety so they reach our client’s as good as he would expect. Packaging Charges Extra.
- High Tensile Fasteners Port of Dispatch: Mumbai or Kalamboli ports in the Maharashtra state of India.
- High Tensile Fasteners Tax: 18% GST
Different types fasteners
Sizes of High Tensile Fasteners
| High Tensile Fasteners Type | Size | Grade | ASME | ISO | ASTM |
|---|---|---|---|---|---|
| ASTM F568 Socket Head Cap Fasteners | M1.6 to M64 | 12.9 | B18.3.1 M | 4762 | A574M |
| Socket Low Head Cap Fasteners | M4 to M20 | 10.9 | |||
| ASTM F568 Socket Head Shoulder Fasteners | M6 to M24 | 012.9 | B18.3.3M | ||
| Countersunk Socket Head Fasteners | M3 to M20 | 012.9 | B18.3.5M | 10642 | F835M |
| ASME SF568 Button Head Socket Fasteners | M3 to M12 | 012.9 | B18.3.4M | 7380 | F835M |
| Flange Button Head Socket Fasteners | M3 to M10 | 012.9 | F835M | ||
| HT Knurled Point Socket Set Fasteners | M3 to M20 | 45H | B18.3.6M | 4029 | F912M |
| Flat Point Socket Set Fasteners | M6 to M12 | 45H | B18.3.6M | 4026 | F912M |
| Dog Point Socket Set Fasteners | M3 to M20 | 45H | B18.3.6M | 4028 | F912M |
| Cone Point Socket Set Fasteners | M3 to M12 | 45H | B18.3.6M | 4027 | F912M |
| HT Plain Point Socket Set Fasteners | M3 to M20 | 45H | B18.3.6M | 4029 | F912M |
| Taper Pressure Plug | M8 to M22 | – |
| High Tensile Fasteners Type | Size | Property Class | Tensile Strength | Standard |
|---|---|---|---|---|
| Hex Head Fasteners | M4 to M80 | 10.9 | 1040N / mm2 min | ISO 4017 (Full Thread) ISO 4014 (Half Thread) |
| High Tensile Nuts Type | Size | Property Class | Standard |
|---|---|---|---|
| M10 HT Hex Nut | M6 to M42 | 10 | ISO 4032 |
| HT Nylock Nut | M6 to M20 (Gr.8) M10 to M24 (Gr.10) |
8 & `10 | DIN 982 |
| M8 HT Nylock Nut | M6 to M20 (Gr.8) M10 to M24 (Gr.10) |
8 & 10 | DIN 985 |
| HT Hex Weld Nut | M6 to M12 | 8 | DIN 929 |
| High Tensile Washers Type | Size | Hardness | Standard |
|---|---|---|---|
| Square Section Spring Washer, High Tensile | 3mm to 39mm | HV (430 to 530) | DIN 7980 |
| Flat Section Spring Washer, High Tensile | 3mm to 39mm | HV (430 to 530) | DIN 127 B |
| Hardened Washer, High Tensile | 12mm to 30mm | HV (300 to 370) | IS 2016 |
| Hardened Steel Washer, High Tensile | 12mm to 56mm | Rockwell 26 to 45 (HDG) Rockwell 38 to 45 (Coated) |
ASTM F436M |
