ASTM A193 Grade B8 Class 1 Sample MTC Certificate
Access a comprehensive, professionally formatted Material Test Certificate according to EN 10204-2004: 3.1 for ASTM A193 Grade B8 Class 1 (AISI 304 / UNS S30400). Inspect the exact documentation your QA and engineering teams will receive with every Ananka Fasteners order.
What's Inside This ASTM A193 B8 Class 1 MTC Certificate
This sample mill test certificate mirrors the rigorous QA documentation package standard for highly durable austenitic stainless steel fasteners shipped from Ananka Fasteners Pvt Ltd.
- Full Traceability: Certified with TC No.: S85/26-XX and corresponding ASTM specifications.
- Chemical Compliance: Detailed breakdowns verifying the classic 18/8 composition—roughly 18.00% Chromium and 8.00% Nickel—providing excellent corrosion resistance across broad industrial applications.
- Class 1 Carbide Solution Treated: Verification that the material is solution annealed and un-strain-hardened, ensuring optimal ductility and maintaining structural integrity in high-temperature service.
- Mechanical Properties: Comprehensive reporting of Tensile Strength (Min 515 MPa), Yield Strength (Min 205 MPa), Elongation (Min 30%), and a maximum Hardness of 96 HRB.
- Quality Compliance: 100% visual inspection carried out and verified free from defects and radioactive contamination.
Live Preview: ASTM A193 Grade B8 Class 1 MTC Data
Review the standard parameters and layout before downloading the full document.
TC Number
S85/26-XX
TC Date
12.06.20XX
Material Spec
ASTM A193 Grade B8 Class 1 UNS S30400
Bar Shape / Size
Hex Bolt / M20
Dimensions / Item
Hex Bolt M20-2.5P x 100 mm
Quantity
25.00 NOS
Chemical Composition %
| C | Mn | P | S | Si | Cr | Ni | Fe |
|---|---|---|---|---|---|---|---|
| 0.050 | 1.45 | 0.025 | 0.010 | 0.60 | 18.50 | 8.50 | Rem |
| Max: 0.08 | Max: 2.00 | Max: 0.045 | Max: 0.030 | Max: 1.00 | Min: 18.00 Max: 20.00 |
Min: 8.00 Max: 11.00 |
Rem |
Mechanical Properties
| TENSILE STRENGTH (Mpa) | YIELD STRENGTH 0.2% Offset (Mpa) | % ELONGATION (GL-50mm) | HARDNESS (HRB) |
|---|---|---|---|
| 580.00 | 240.00 | 45.00 | 85, 84, 86 |
| Min: 515 | Min: 205 | Min: 30 | Max: 96 |
Standard References & Compliance
Our MTC certificates map to the demanding industrial standards for fasteners. The test reports confirm compliance with As Per ASME/ASTM A193 Grade B8 Class 1 UNS S30400 with respect to the tests carried out.
| Standard / Requirement | Confirmation on Certificate |
|---|---|
| Visual Inspection | 100% visual inspection carried out & found free from defects. |
| Safety Requirements | Material is free from radioactive contamination. |
| Weld Repairs | No weld repair Perform. |
| Dimensional Accuracy | All Dimensions are as per PO Specification. |
Certification Details
We confirm that above mentioned Items was Manufactured, Sampled, Tested and Inspected in accordance with the subjected Customer's Purchase Order and as applicable Drawings, Material Specifications, Codes & Standards and the results of the items have been determined to meet the users' requirements.
Documentation Standard
- EN 10204-2004: 3.1 Standard
- Free from radioactive contamination
- Certified ISO 9001: 2015 Company
Heat Treatments
- Carbide Solution Treated (Annealed)
- Quenching Medium: Water quenched
Testing Conditions
- Chemical, Mechanical & hardness test carried at room temperature 25°C
- 100% visual inspection carried out
Technical FAQs — ASTM A193 Grade B8 Class 1 MTC Certificate
What is the significance of "Class 1" in ASTM A193 Grade B8?
Class 1 indicates that the fasteners have been carbide solution treated (annealed) but not strain-hardened. This provides an excellent balance of ductility and corrosion resistance with a maximum hardness of 96 HRB, distinguishing it from Class 2 fasteners, which are intentionally strain-hardened to achieve higher tensile and yield strength.
What environments are Grade B8 Class 1 bolts best suited for?
Manufactured from AISI 304 stainless steel, Grade B8 Class 1 bolts are the industry standard for general high-temperature service and highly corrosive environments. They are widely specified in chemical processing, petrochemical refining, food processing, and power generation due to their reliable oxidation resistance and structural stability.
Are the materials verified to be free from radioactive contamination?
Yes, the MTC document strictly states that the material has been verified as free from radioactive contamination and has undergone a 100% visual inspection to ensure it is completely free from manufacturing defects before dispatch.
