ASTM A193 Grade B8M Class 1 Sample MTC Certificate
Access a comprehensive, professionally formatted Material Test Certificate according to EN 10204-2004: 3.1 for ASTM A193 Grade B8M Class 1 (AISI 316 / UNS S31600). Inspect the exact documentation your QA and engineering teams will receive with every Ananka Fasteners order.
What's Inside This ASTM A193 B8M Class 1 MTC Certificate
This sample mill test certificate mirrors the rigorous QA documentation package standard for highly durable marine-grade austenitic stainless steel fasteners shipped from Ananka Fasteners Pvt Ltd.
- Full Traceability: Certified with TC No.: S91/26-XX and corresponding ASTM specifications.
- Molybdenum Enriched Chemistry: Detailed breakdowns verifying the addition of 2.00% - 3.00% Molybdenum. This critical element vastly improves resistance to pitting and crevice corrosion in chloride environments (like seawater) compared to standard B8 (304) grades.
- Class 1 Carbide Solution Treated: Verification that the material is solution annealed and un-strain-hardened, ensuring maximum corrosion resistance and excellent ductility under extreme conditions.
- Mechanical Properties: Comprehensive reporting of Tensile Strength (Min 515 MPa), Yield Strength (Min 205 MPa), Elongation (Min 30%), and a strictly controlled maximum Hardness of 96 HRB.
- Quality Compliance: 100% visual inspection carried out and verified free from defects and radioactive contamination.
Live Preview: ASTM A193 Grade B8M Class 1 MTC Data
Review the standard parameters and layout before downloading the full document.
TC Number
S91/26-XX
TC Date
20.09.20XX
Material Spec
ASTM A193 Grade B8M Class 1 UNS S31600
Bar Shape / Size
Round Bar / 16 mm
Dimensions / Item
Hex Bolt M16-2.0P x 80 mm
Quantity
50.00 NOS
Chemical Composition %
| C | Mn | P | S | Si | Cr | Ni | Mo | Fe |
|---|---|---|---|---|---|---|---|---|
| 0.045 | 1.30 | 0.025 | 0.010 | 0.50 | 16.80 | 10.50 | 2.10 | Rem |
| Max: 0.08 | Max: 2.00 | Max: 0.045 | Max: 0.030 | Max: 1.00 | Min: 16.00 Max: 18.00 |
Min: 10.00 Max: 14.00 |
Min: 2.00 Max: 3.00 |
Rem |
Mechanical Properties
| TENSILE STRENGTH (Mpa) | YIELD STRENGTH 0.2% Offset (Mpa) | % ELONGATION (GL-50mm) | HARDNESS (HRB) |
|---|---|---|---|
| 540.00 | 225.00 | 42.00 | 86, 88, 85 |
| Min: 515 | Min: 205 | Min: 30 | Max: 96 |
Standard References & Compliance
Our MTC certificates map to the demanding industrial standards for fasteners. The test reports confirm compliance with As Per ASME/ASTM A193 Grade B8M Class 1 UNS S31600 with respect to the tests carried out.
| Standard / Requirement | Confirmation on Certificate |
|---|---|
| Visual Inspection | 100% visual inspection carried out & found free from defects. |
| Safety Requirements | Material is free from radioactive contamination. |
| Weld Repairs | No weld repair Perform. |
| Dimensional Accuracy | All Dimensions are as per PO Specification. |
Certification Details
We confirm that above mentioned Items was Manufactured, Sampled, Tested and Inspected in accordance with the subjected Customer's Purchase Order and as applicable Drawings, Material Specifications, Codes & Standards and the results of the items have been determined to meet the users' requirements.
Documentation Standard
- EN 10204-2004: 3.1 Standard
- Free from radioactive contamination
- Certified ISO 9001: 2015 Company
Heat Treatments
- Carbide Solution Treated (Annealed)
- Quenching Medium: Water quenched
Testing Conditions
- Chemical, Mechanical & hardness test carried at room temperature 25°C
- 100% visual inspection carried out
Technical FAQs — ASTM A193 Grade B8M Class 1 MTC Certificate
What is the difference between Grade B8 and Grade B8M?
Grade B8 is manufactured from AISI 304 stainless steel, while Grade B8M is manufactured from AISI 316. The key difference shown on the MTC is the addition of 2.00% to 3.00% Molybdenum in B8M. This significantly enhances the fastener's resistance to pitting and crevice corrosion, making it the preferred choice for marine, offshore, and harsh chemical environments.
What does "Class 1" mean for B8M fasteners?
Class 1 denotes that the fasteners have been carbide solution treated (annealed) but not intentionally strain-hardened. This provides excellent ductility and corrosion resistance, keeping the maximum hardness to 96 HRB. By contrast, Class 2 fasteners are strain-hardened to achieve higher tensile and yield strength, though they sacrifice some ductility in the process.
Are the materials verified to be free from radioactive contamination?
Yes, the MTC document strictly states that the material has been verified as free from radioactive contamination and has undergone a 100% visual inspection to ensure it is completely free from manufacturing defects before dispatch.
