Titanium Grade 2 (UNS R50400) Sample MTC
Access a comprehensive, professionally formatted Material Test Certificate according to EN 10204-2004: 3.1 for Commercially Pure Titanium Grade 2 (ASTM B348 UNS R50400). Inspect the exact documentation your QA and engineering teams will receive with every highly corrosion-resistant fastener order from Ananka Fasteners.
What's Inside This Titanium Grade 2 MTC Certificate
This sample mill test certificate mirrors the rigorous QA documentation package standard for the "workhorse" of the titanium industry. Grade 2 fasteners are utilized across chemical processing, desalination, marine, and medical applications due to their exceptional corrosion resistance and excellent formability.
- Full Traceability: Certified with TC No.: S74/26-XX and corresponding ASTM B348 specifications for Commercially Pure (CP) Titanium rod and bar.
- Commercially Pure Chemistry: Detailed breakdowns verifying the unalloyed Titanium balance and strict controls over Oxygen (O) and Iron (Fe), which dictate the precise strength and ductility levels distinguishing Grade 2 from Grades 1, 3, and 4.
- Corrosion Immunity: Confirms the metallurgy required to maintain a highly stable, continuous, and protective oxide film, rendering it virtually immune to attack in seawater, wet chlorine, and organic acids.
- Mechanical Properties (Annealed): Comprehensive reporting of Tensile Strength (420.50 MPa), Yield Strength (315.20 MPa), Elongation (25.50%), and Hardness (165 HB), demonstrating the perfect balance of moderate strength and high ductility.
- Quality Compliance: 100% visual inspection carried out and verified free from defects and radioactive contamination.
Live Preview: Titanium Grade 2 (Annealed) MTC Data
Review the standard parameters and layout before downloading the full document.
TC Number
S74/26-XX
TC Date
08.07.20XX
Material Spec
ASTM B348 UNS R50400 Annealed
Bar Shape / Size
Hex Bar / 12 mm
Dimensions / Item
Hex Head Bolt M12 x 45 mm
Quantity
10.00 NOS
Chemical Composition %
| N | C | H | Fe | O | Residuals (Each) | Residuals (Total) | Ti |
|---|---|---|---|---|---|---|---|
| 0.015 | 0.022 | 0.005 | 0.150 | 0.160 | <0.10 | <0.40 | Rem |
| Max: 0.030 | Max: 0.080 | Max: 0.015 | Max: 0.300 | Max: 0.250 | Max: 0.10 | Max: 0.40 | Rem |
Mechanical Properties
| TENSILE STRENGTH (Mpa) | YIELD STRENGTH 0.2% Offset (Mpa) | % ELONGATION (GL-50mm) | HARDNESS (HB) |
|---|---|---|---|
| 420.50 | 315.20 | 25.50 | 165 |
| Min: 345 | 275 - 450 | Min: 20 | Max: 200 |
Standard References & Compliance
Our MTC certificates map to the demanding industrial standards for specialty alloy fasteners. The test reports confirm compliance with As Per ASME/ASTM B348 UNS R50400 with respect to the tests carried out.
| Standard / Requirement | Confirmation on Certificate |
|---|---|
| Visual Inspection | 100% visual inspection carried out & found free from defects. |
| Safety Requirements | Material is free from radioactive contamination. |
| Weld Repairs | No weld repair Perform. |
| Dimensional Accuracy | All Dimensions are as per PO Specification. |
Certification Details
We confirm that above mentioned Items was Manufactured, Sampled, Tested and Inspected in accordance with the subjected Customer's Purchase Order and as applicable Drawings, Material Specifications, Codes & Standards and the results of the items have been determined to meet the users' requirements.
Documentation Standard
- EN 10204-2004: 3.1 Standard
- Free from radioactive contamination
- Certified ISO 9001: 2015 Company
Metallurgy & Treatment
- Commercially Pure (Unalloyed) Titanium
- Fully Annealed Condition for Maximum Ductility
Testing Conditions
- Chemical, Mechanical & hardness test carried at room temperature 25°C
- 100% visual inspection carried out
Technical FAQs — Titanium Grade 2 MTC Certificate
Why is Titanium Grade 2 the "Workhorse" of the industry?
Titanium Grade 2 is Commercially Pure (CP) titanium that offers the best overall balance of traits among the unalloyed grades. It provides moderate strength, excellent cold formability and ductility, and outstanding resistance to corrosion in highly oxidizing environments (like seawater, wet chlorine, and nitric acid). It is the most widely used titanium grade for industrial applications.
Why are Interstitial Elements (O, Fe, N, C) so important on this MTC?
Because Titanium Grade 2 is unalloyed, its mechanical strength is entirely determined by its interstitial elements—primarily Oxygen and Iron. Tight controls over these trace amounts dictate the difference between Grade 1 (softest/most ductile), Grade 2 (balanced), and Grades 3/4 (higher strength/lower ductility). The MTC proves the precise chemistry required to hit Grade 2 mechanical targets.
Are the materials free from radioactive contamination?
Yes, the document strictly states that the material is free from radioactive contamination and undergoes a 100% visual inspection to ensure it is free from defects.
